The Agilent N7751A combines an attenuator with 2 front-panel power meter channels, offering exceptional performance at a low price. The power meters permit measurements from any point in the measurements setup and assist in calibrating power offsets with respect to the attenuator output.

Extension of N77xx-series

The N7751A attenuator is an extension to Agilent’s high density N77xx-family that establishes a new standard in space-saving fiberoptic instrumentation.

Features and Benefits

• Compact instrument combines and integrates multiple functions for setting attenuation and power levels and optical power measurement to reduce CAPEX and floor space.
• Fast and precise setting of optical power levels with settling times of 100 ms for improved test throughput.
• Active power control to keep output power constant
• The power meters support convenient power offset calibration of the attenuators.
• The instrument can be controlled via LAN and USB, as well as GPIB for compatibility with existing equipment.
• An easy-to-use and intuitive graphical user interface software speeds up the integration process.

Applications

• Optical transceiver testing
• Optical network integration testin
