Agilent/HP/E2697A /High Impedance Adapter
- Agilent/HP/E2697A /High Impedance Adapter
- 欲购买或租赁Agilent/HP/E2697A /High Impedance Adapter?请在线咨询或拔打24小时电话:13715327187
详细资料:
主要技术指标
Bandwidth:
- 500 MHz with 10073C passive probe
Range:
- Dynamic Range: 1:1 +/- 0.8V; 10:1 +/- 8V
- Dynamic Range with 10073C passive probe: 1:1 +/- 8V; 10:1 +/- 80V
- Maximum Input Voltage: +/- 100V
Input Impedance
- 1MOhm +/-1% (~12 pF)
- Input Coupling: dc, ac (7 Hz)
描述
The E2697A high impedance adapter allows connection of probes that require a high impedance input (e.g., passive probes, current probes) to the Infiniium 54850, 80000 and 90000 Series of high performance oscilloscopes. The E2697A high impedance adapter extends the capability of Agilent Infiniium high-performance oscilloscopes, making them ideal for a variety of general-purpose measurements such as power supplies, inverters, semiconductor devices, etc. The E2697A provides switchable ac/dc coupling, as well as 10:1 and 1:1 attenuation settings.
Promotions and Special Offers for Oscilloscopes
仪器保证:
我们的大多数设备在装运之前均经过严格的质量检测与校验。也可申请国家计量证书。
