Agilent/HP/81624A/光功率探头|光探头

• Agilent/HP/81624A/光功率探头|光探头
• 欲购买或租赁Agilent/HP/81624A/光功率探头|光探头？请在线咨询或拔打24小时电话：13715327187

详细资料：

Agilent 81624A|HP-81624A|HP81624A 光功率探头|光探头

品牌：安捷伦 | Agilent | 惠普 | HP

Agilent 81624A Optical Head

Specifications at a glance for the 81624A

- Wavelength Range: 800 to 1700 nm
- Detector Type (Sensor Element): InGaAs
- Detector Size (diameter): 5 mm
- Power Range: +10 to -90 dBm
- Uncertainty at Reference Conditions (-20 dBm): +/- 2.2% (1000 to 1630 nm)
- No Analog Output

Additional Information

The Agilent optical power heads are specially designed for low PDL, low spectral ripple and high return loss and are used for optical component test. The heads come with a magnetic D-shape adapter and provide a safe stand. The optical heads have to be operated with the single (Agilent 81618A) or dual (Agilent 81619A) interface modules.

These modules are controlled in any configuration in any of the mainframes 8163B, 8164B and 8166B. A highly flexible connector interface palette addresses connectorized, bare fiber or open beam application

- Applicable Fiber Type: Standard Single-mode And Multimode max. 100 um core size, NA < 0.3

- Linearity: CW +10 to -70 dBm (1000 - 1630 nm)

- Connector Type Options:

81000FA: FC/PC connector adapter
81000KA: SC/PC connector adapter
81000PA: E-2000 connector adapter
81000VA: ST/PC connector adapter
81003LA : LC/PC connector adapter

仪器保证：

我们的大多数设备在装运之前均经过严格的质量检测与校验。也可申请国家计量证书。
