Tektronix/P6046/探头
- Tektronix/P6046/探头
- 欲购买或租赁Tektronix/P6046/探头?请在线咨询或拔打24小时电话:13715327187
详细资料:
The P6046 is a self-contained active differential system consisting of a differential probe, amplifier and power supply. Active FET amplifiers at the dual-inputs reduce circuit loading. Combined with the differential processing occuring in the probe head, the P6046 provides superior common mode rejection ratios (CMRR) at high frequencies typically 10,000:1 out to 50 kHz, derating to 5,000:1 at 1 MHz.
Since the P6046 is self-contained, it provides a differential output into a single oscilloscope channel. System controls enable you to select AC or DC coupling, adjust the DC balance and select mV/div from 1 to 200mV (10mV to 2V with attenuator head) in standard 1,2,5 steps.
A slip-on 10X attenuator is also included which increases the maximum input voltage from +/-25V to +/-250V and the common mode dynamic range from +/-5V to +/-50V.
仪器保证:
我们的大多数设备在装运之前均经过严格的质量检测与校验。也可申请国家计量证书。
